Wooden Aluminum Cladding Panel
Wood Series
The wooden aluminum cladding panel sheet consists of a metal profiled core (non-combustible), which is laminated between two skins of aluminium in various thickness options. Suitable for exterior/interior wall cladding decoration.
Main Features
- Regular Size: 1250x2600mm
- Width: 1250mm, 1550mm
- Length: Max 6000mm
- Overall Thickness: 2.5mm-5.0mm
- Top Aluminum thickness: 0.5mm-0.7mm
- Surface treatment: Polyester, fluorocarbon, drawing, mirror, anti - scratch, wood grain, stone grain, PP film, leather/cotton, etc
- Coating: PVDF, PE
- Weight: 3.8kg/m2 in 3.5mm thickness
- Fireproof grade: A2 fire safety
- Warranty: 15years
- Package info: wooden pallet, 8 pallets/20GP, 16 pallets/40GP
- MOQ: 300 square meters
Aluminum Non-combustible Panel is a lightweight, strong, and extremely rigid wooden aluminum cladding panel sheet which is an optimal solution for a wide range of applications in the architectural, transport, furniture, and sign industry. Suitable for exterior/interior wall cladding/facades/home decoration.
Available in 2.5-5.0 mm thickness, the timber aluminum cladding panel sheet consists of a metal profiled core (non-combustible), which is laminated between two skins of aluminum in various thickness options.
It has reached the A2 fire level, passed ASTM-E84, EN13501, the AS1530 fire test, and certification.
Physical Data of Wooden Aluminum Cladding Panel
| Item | Data |
|---|---|
| Flattening Strength | 0.85Mpa |
| Pressing Strength | 4.39Mpa |
| Shear Strength | 0.85Mpa |
| Handle Length | 145mm |
| Bending Strength: | 161.9Mpa |
| Roller Peel Strength: | 102.7N.mm/mm |
| Edgefold Semidiameter: | <1mm |
| High temperature on toxicity: | NONE |
Test Classification of Wooden Aluminum Cladding Panel
| Test Item | Remark |
|---|---|
| AS1530.1/3 | Fire test |
| BS476-6/7 | Fire test |
| EN13501-1 | Fire test |
| ASTM E84 | Fire test |
| ASTM D732-17 | Shear Strength |
| ASTM D903-98 | Peel Strength |
| ASTMC297/C397M-16 | Flatwise Tensile Strength |
| AAMA 2605-20 | Muriatic Acid Resistance |
| ASTM C365/C365M-16 | Flatwise Compressive Strength |
| ASTM E8/E8M | Tensile test |
| with reference to EN-717-1:2004, analysis was preformed by UV-Vis | Formaldehyde |
| ASTM G 21-15 | Antimicrobial activity test |
Color Selection
Ork Willow Wood
Willow Wood Texture
Willow Wood
Red Copper Wood
Aspen Wood
Red Maple Texture
Red Maple
Wenge Texture
landscape pine Texture
Black Walnut
